Lifeline PVX-12150HT Battery
Product Availability: Moving Quickly
SKU:
PVX-12150HT
PVX-12150HT
SOLD OUT- BACKORDERS ARE ACCEPTED
- The SunXtender PVX-12150HT boasts industry-leading life cycles providing safe, reliable, and long-lasting power.
- Recombinant gas SunXtender Deep Cycle AGM Series solar batteries are low resistance, valve-regulated lead-acid (VRLA) batteries.
- Non-Spillable maintenance-free construction allows the battery to be used upright, on it's end or side.
- Features PolyGuard™ Microporous Polyethylene Separators shielding the positive plates against shorting, shock or vibration.
- There is no exposed lead on SunXtender batteries and they are 100 percent recyclable making them environmentally friendly.
- Designed for photovoltaic applications for superior & reliable solar power.
- Low Self Discharge Rate Approximately 1 % per month at 25° C (77° F).
- Ships UL approved, HAZMAT Exempt, DOT HMR40 compliant, and fully charged ready to install.
| Volts |
2v |
|---|---|
| BCI Group Reference |
L16 |
| Length in. (mm) |
11.64" (296mm) |
| Width in. (mm) |
6.95" (177mm) |
| Height in. (mm) |
15.73" (399mm) |
| Weight lbs (kg) |
124 lbs (56.2 kg) |
| Standard Terminal |
M8 |
| Nominal Capacity Ampere Hours @ 77°F (25°C) (To 1.75 volts per cell) |
|
| 1 hr Rate |
798 Ah |
| 2 hr Rate |
1035 Ah |
| 4 hr Rate |
1080 Ah |
| 8 hr Rate |
1128 Ah |
| 24 hr Rate |
1215 Ah |
| Part Number | Description | Nom. Volts | CCA @ -18°C | Amp /Hr @C20 Rate | Reserve Capacity mins @25A | Terminal layout with Term closest | Length mm | Width mm | Height mm | Weight Lbs |
| GPL-U1T | Lifeline 12V 33AH AGM Battery (USA 24-4/ U1) | 12 | 215 | 33 | 50 | +TI - | 196 | 132 | 175 | 24.03036 |
| GPL-24T | Lifeline 12V 80AH AGM Battery (USA N50Z) | 12 | 550 | 80 | 149 | + MC - | 283 | 168 | 235 | 56.21781 |
| GPL-27T | Lifeline 12V 100AH AGM Battery (USA N70ZZ) | 12 | 575 | 100 | 186 | + MC - | 333 | 168 | 235 | 65.03629 |
| GPL-31T | Lifeline 12V 105AH AGM Battery (USA 86) | 12 | 600 | 105 | 195 | + MC - | 328 | 172 | 236 | 69.22507 |
| GPL-31XT | Lifeline 12V 125AH AGM Battery (USA 86 approx) | 12 | 650 | 125 | 230 | + MC - | 328 | 172 | 236 | 74.95708 |
| GPL-30HT | Lifeline 12V 150AH AGM Battery (USA 89) | 12 | 700 | 150 | 315 | + MC - | 342 | 172 | 304 | 95.90097 |
| GPL-4DA | Lifeline 12V 210AH AGM Battery (USA N150) | 12 | 1100 | 210 | 390 | ± End SAE | 527 | 222 | 257 | 134.9227 |
| GPL-4DL | Lifeline 12V 210AH AGM Battery (USA N150) | 12 | 1100 | 210 | 390 | ± L blade | 527 | 222 | 266 | 134.9227 |
| GPL-8DA | Lifeline 12V 255AH AGM Battery (USA N200) | 12 | 1350 | 255 | 475 | ± End SAE | 527 | 278 | 251 | 162.26 |
| GPL-8DL | Lifeline 12V 255AH AGM Battery (USA N200) | 12 | 1350 | 255 | 475 | ± L blade | 527 | 278 | 260 | 162.26 |
| GPL-1400T | Lifeline 12V 55AH AGM Battery Starting | 12 | 550 | 45 | 90 | - TI + | 249 | 132 | 174 | 31.96699 |
| GPL-2400T | Lifeline 12V 75AH AGM Battery Starting | 12 | 650 | 75 | 172 | RHP TI | 282 | 168 | 235 | 53.13134 |
| GPL-2700T | Lifeline 12V 95AH AGM Battery Starting (USA N70Z) | 12 | 745 | 95 | 206 | - TI + | 333 | 168 | 227 | 63.05213 |
| GPL-3100T | Lifeline 12V 100AH AGM Battery Starting (USA 86) | 12 | 810 | 100 | 228 | - TI + | 328 | 172 | 236 | 67.02045 |
| GPL-4C | Lifeline 6V 220AH AGM Battery (US2200/GC2) | 6 | 760 | 220 | 492 | Offset TI | 261 | 181 | 294 | 66.1386 |
| GPL-6C | Lifeline 6V 300AH AGM Battery (USA tall GC2) | 6 | 925 | 300 | 692 | Offset TI | 262 | 180 | 330 | 89.9485 |
| GPL-L16T | Lifeline 6V 400AH AGM Battery (USA L16) | 6 | 135 | 400 | 950 | Offset TI | 296 | 177 | 399 | 119.0495 |
| GPL-31T-2V | Lifeline 2V 630AH AGM Battery (USA 86) Dual Ti terms | 2 | 3240 | 630 | 1170 | Dual TIs | 328 | 172 | 227 | 69.22507 |
| GPL-4CT-2V | Lifeline 2V 660AH AGM Battery (USA GC2/US2200 approx) | 2 | 2025 | 660 | 1476 | Offset TI | 261 | 181 | 294 | 70.10692 |
| GPL-6CT-2V | Lifeline 2V 900AH AGM Battery (USA tall GC2 approx) | 2 | 2500 | 900 | 2076 | Offset TI | 262 | 181 | 330 | 93.91681 |
| GPL-L16T-2V | Lifeline 2V 1200AH AGM Battery (USA L16) | 2 | 3645 | 1200 | 2850 | Offset TI | 296 | 177 | 399 | 119.0495 |
| LL-1640TB | Lifeline 16V 40AH AGM Racing Serie | 16 | 1050 | 40 | 85 | LHP SAE | 258 | 167 | 205 | 368.1715 |
